Helios M
The Helios M is a compact architectural luminaire designed to deliver subtle, elegant illumination for walkways,
garden paths, and private landscapes. Featuring a shade diameter of 344 mm, its refined halo-ring design casts a warm,
downward-directed light that enhances safety without harsh glare.
Crafted with a durable matte black finish, the Helios M combines contemporary minimalist aesthetics with reliable outdoor performance,
making it an ideal choice for smaller-scale residential and commercial projects.
Download Files:
Applications: Street and urban lighting.
Tilt angle: None
Weight: 8.82s Lbs / 4 kg
EPA: Side: 0.4 ft2 (0.038m2)
Top: 2.04 ft2 (0.19m2)
(Cross Section Surface)
Use Drag coefficient factor - 0.5
Mounting: M2B - 2 3/8” x 4 ”L (60 mm x 100 mm L)
Power Factor: >0.9 (full load)
Power cable: 12GA
Connector-IP68: Cable Dia. 0.27”-0.39”
(7mm-10mm)
Optical unit lifetime
(Ta: 77°F/25°C)
350mA: L90B10 ≥ 100 000 h
(Including critical failures)
L90 > 100 000 h, TM-21
...
700mA: L90B10 ≥ 100 000 h
(Including critical failures)
L90 > 100 000 h, TM-21
