Helios L
The Helios L is a commanding outdoor luminaire built to make a bold statement in larger architectural and landscape settings.
Equipped with an expansive 481 mm diameter shade, this model provides superior light distribution, ideal for wide pedestrian avenues,
public plazas, and spacious green areas. Its iconic illuminated ring offers uniform, glare-free light,
while the robust black-finished column ensures seamless integration into modern urban environments.
Download Files:
Applications: Street and urban lighting.
Tilt angle: None
Weight: 15.87 Lbs / 7.2 kg
EPA: Side: 0.4 ft2 (0.038m2)
Top: 2.04 ft2 (0.19m2)
(Cross Section Surface)
Use Drag coefficient factor - 0.5
Mounting: M2B - 2 3/8” x 4 ”L (60 mm x 100 mm L)
Power Factor: >0.9 (full load)
Power cable: 12GA
Connector-IP68: Cable Dia. 0.27”-0.39”
(7mm-10mm)
Optical unit lifetime
(Ta: 77°F/25°C)
350mA: L90B10 ≥ 100 000 h
(Including critical failures)
L90 > 100 000 h, TM-21
...
700mA: L90B10 ≥ 100 000 h
(Including critical failures)
L90 > 100 000 h, TM-21
